"BP Gate" Oil Spill Caused By Gas Bubble, Worse Than Exxon Valdez

Report: Gas bubble Triggered Rig Blast

The deadly blowout of an oil rig in the Gulf of Mexico was triggered by a bubble of methane gas that escaped from the well and shot up the drill column, rig workers have told BP's Internal Investigators.

The oil started spilling after the methane bubble expanded quickly and burst through several seals and barriers before exploding, according to a timeline described in documents revealed to the Associated Press.

The documents provide the most detailed account of what may have caused the April 20 blast that killed 11 workers.

Revelations of the workers' descriptions came as at least one scientist expressed concern that the resulting spill already has grown larger than the massive Exxon Valdez disaster of 1989 and dumped as much as 13 million gallons of crude into waters off the U.S. coastline.

U.S. official say the underwater gusher has poured out more than 3 million gallons of crude. But Ian MacDonald, a biological oceanographer at Florida State University, told Reuters on Friday that official flow-rate estimates of 5,000 barrels (210,000 gallons) a day since the Deepwater Horizon rig exploded were much too conservative.

The real flow rate from the undersea well, based on aerial images of the oil slick and estimates of the thickness of the oil itself, is probably closer to 25,000 barrels (1,050,000 gallons) a day, MacDonald said.

A spokesperson for the National Oceanic and Atmospheric Administration, which has been monitoring the oil spill, said no one was immediately available to comment on possible revisions of the oil spill's size.

The Exxon Valdez tanker ship spilled about 11 million gallons of oil into Alaska's Prince William Sound, in one of the world's worst environmental disasters ever. If his own estimate is accurate, MacDonald said BP's oil spill was already larger than its 1989 rival.

Investigation details revealed

Portions of the rig-workers interviews, two written and one taped, were described in detail to the AP by Robert Bea, a University of California Berkeley engineering professor who serves on a National Academy of Engineering panel on oil pipeline safety and worked for BP PLC as a risk assessment consultant during the 1990s. He received them from industry friends seeking his expert opinion.

A group of BP executives were on board the Deepwater Horizon rig celebrating the project's safety record, according to the transcripts. Meanwhile, far below, the rig was being converted from an exploration well to a production well.

Based on the interviews, Bea believes that the workers set and then tested a cement seal at the bottom of the well. Then they reduced the pressure in the drill column and attempted to set a second seal below the sea floor. A chemical reaction caused by the setting cement created heat and a gas bubble which destroyed the seal.

Deep beneath the seafloor, methane is in a slushy, crystalline form. Deep sea oil drillers often encounter pockets of methane crystals as they dig into the earth.

As the bubble rose up the drill column from the high-pressure environs of the deep to the less pressurized shallows, it intensified and grew, breaking through various safety barriers, Bea said.

"A small bubble becomes a really big bubble," Bea said. "So the expanding bubble becomes like a cannon shooting the gas into your face."

'Swoosh, boom, run'

Up on the rig, the first thing workers noticed was the seawater in the drill column suddenly shooting back out at them, rocketing 240 feet in the air. Then, the gas surfaced. Then the oil.

"What we had learned when I worked as a drill rig laborer was swoosh, boom, run," Bea said. "The swoosh is the gas, boom is the explosion and run is what you better be doing."

The gas flooded into an adjoining room with exposed ignition sources, he said.

"That's where the first explosion happened," said Bea, who worked for Shell Oil in the 1960s during the last big northern Gulf of Mexico oil well blowout. "The mud room was next to the quarters where the party was. Then there was a series of explosions that subsequently ignited the oil that was coming from below."

The executives were injured but survived. Nine rig crew on the rig floor and two engineers died, according to one account.

"The furniture and walls trapped some and broke some bones but they managed to get in the life boats with assistance from others," said the transcript.

The reports made the 73-year-old industry veteran cry.

"It sure as hell is painful," he said. "Tears of frustration and anger."

BP spokesman Daren Beaudo said he could not immediately comment on the report.

Containment Box lowered

On Friday, a BP-chartered vessel lowered a 100-ton concrete-and-steel vault onto the ruptured well, an important step in a delicate and unprecedented attempt to stop most of the gushing crude fouling the sea.

"We are essentially taking a four-story building and lowering it 5,000 feet and setting it on the head of a pin," BP spokesman Bill Salvin told The Associated Press.

Underwater robots guided the 40-foot-tall box into place in a slow-moving drama. Now that the contraption is on the seafloor, workers will need at least 12 hours to let it settle and make sure it's stable before the robots can hook up a pipe and hose that will funnel the oil up to a tanker.

"It appears to be going exactly as we hoped," on Friday afternoon, shortly after the four-story device hit the seafloor. "Still lots of challenges ahead, but this is very good progress."

By Sunday, the box the size of a house could be capturing up to 85 percent of the oil.

The task became increasingly urgent as toxic oil crept deeper into the bays and marshes of the Mississippi Delta.

A sheen of oil began arriving on land last week, and crews have been laying booms, spraying chemical dispersants and setting fire to the slick to try to keep it from coming ashore. But now the thicker, stickier goo — arrayed in vivid, brick-colored ribbons — is drawing ever closer to Louisiana's coastal communities.

Never tried before

There are still untold risks and unknowns with the containment box: The approach has never been tried at such depths, where the water pressure is enough to crush a submarine, and any wrong move could damage the leaking pipe and make the problem worse. The seafloor is pitch black and the water murky, though lights on the robots illuminate the area where they are working.

If the box works, another one will be dropped onto a second, smaller leak at the bottom of the Gulf.

At the same time, crews are drilling sideways into the well in hopes of plugging it up with mud and concrete, and they are working on other ways to cap it.

Investigators looking into the cause of the explosion have been focusing on the so-called blowout preventer. Federal regulators told The Associated Press Friday that they are going to examine whether these last-resort cutoff valves on offshore oil wells are reliable.

Blowouts are infrequent, because well holes are blocked by piping and pumped-in materials like synthetic mud, cement and even sea water. The pipes are plugged with cement, so fluid and gas can't typically push up inside the pipes.

Instead, a typical blowout surges up a channel around the piping. The narrow space between the well walls and the piping is usually filled with cement, so there is no pathway for a blowout. But if the cement or broken piping leaves enough space, a surge can rise to the surface.

There, at the wellhead of exploratory wells, sits the massive steel contraption known as a blowout preventer.

It can snuff a blowout by squeezing rubber seals tightly around the pipes with up to 1 million pounds of force. If the seals fail, the blowout preventer deploys a last line of defense: a set of rams that can slice right through the pipes and cap the blowout.

Deepwater Horizon was also equipped with an automated backup system called a Deadman. It should have activated the blowout preventer even if workers could not.

Based on the interviews with rig workers, none of those safeguards worked.

View Larger Map

Sources: CNN, Huffington Post, MSNBC, TIME, Wikipedia, Youtube, Google Maps
